1964 ALLIS-CHALMERS D-19

Motortopia Staff . 15th December, 2021
0 Likes
  • 1964 ALLIS-CHALMERS D-19
  • 1964 ALLIS-CHALMERS D-19
  • 1964 ALLIS-CHALMERS D-19
  • 1964 ALLIS-CHALMERS D-19
  • 1964 ALLIS-CHALMERS D-19

Vehicle Details

Owner/ Builder

Vehicles Highlights

Manufacturing year: 1964

Engine:

ENGINE

  • AC/Buda D262

DISPLACEMENT

  • 262 ci

BORE & STROKE

  • 3.56 x 4.38 in.

*RATED PTO POWER

  • 66.92 hp @ 2,000 rpm

*RATED DRAWBAR POWER

  • 61.27 @ 2,001 rpm

COMPRESSION RATIO

  • 14:1 (later 15:1)

TRANSMISSION

  • 8-speed (4-speed with Power Director)

Transmission:

Exterior Color:

Interior Color:

Specification

.

ENGINE

  • AC/Buda D262

DISPLACEMENT

  • 262 ci

BORE & STROKE

  • 3.56 x 4.38 in.

*RATED PTO POWER

  • 66.92 hp @ 2,000 rpm

*RATED DRAWBAR POWER

  • 61.27 @ 2,001 rpm

COMPRESSION RATIO

  • 14:1 (later 15:1)

TRANSMISSION

  • 8-speed (4-speed with Power Director)

.

WHEELBASE

  • 102.3 in.

WEIGHT

  • 6,480 lbs.

TIRES

  • Front—7.50-16
  • Rear—18.4-34

*FUEL CONSUMPTION

  • 5.211 GPA at maximum power

*DRAWBAR PULL

  • 8,459 lbs (ballasted to 11, 210 lbs)

*TOP SPEED

  • 13.9 mph
*As rated by Nebraska Tractor Test #811
